* 5 Year Manufacturer Limited Warranty *
The Blade series has been sold worldwide now for over 20 years. The 520SL is the latest edition to the agricultural lineup. A combination of elements developed over a decade of hard work within the agricultural industry, the 520SL boasts a long list of key features. This workhorse ATV is ideal for any agricultural situation.
Powered by the tried and tested TGB 503cc high torque engine, but now equipped with Electronic fuel injection.
The Blade 520SL is T3 homologated so can be registered for road use.
|Bore & Stroke||92 X 75.6 mm|
|Clutch||Automatic - CVT|
|Drive Type||2/4 Wheel Drive Selectable|
|Electrical Outlet Connector||DC 12V 10A 120W|
|Engine Type||4-Stroke Single Cylinder|
|Front Shock Absorbers||Preload Adjustable Hydraulic|
|Front Suspension||Fully Adjustable|
|Front Tyre Size||AT25 x 8-12|
|Front Wheel Size||12"|
|Fuel System||EFI - Electronic Fuel Injection|
|Fuel Tank Capacity||18 Litres|
|Ground Clearance||305 mm|
|Max Power||40HP (OFF ROAD)|
|Max Torque||46.1 NM|
|Overall Height||1502 mm|
|Overall Length||2120 mm|
|Overall Width||1240 mm|
|Rear Shock Absorbers||Preload Adjustable Hydraulic|
|Rear Suspension||Swing Arm|
|Rear Tyre Size||AT25 x 10-12|
|Rear Wheel Size||12"|
|Start Type||Electric Start|
|Transmission Type||V-belt CVT Automatic|
|Unbraked Towing Capacity||850 kg|
|Warranty||5 Year Manufacturer Limited Warranty|
|Wheel Size||12 Inch|
